Xaar 50X Series

Gain competitive advantage with exceptional print quality and industrial reliability

Reach higher levels of performance in wide-format graphics and industrial printing. The Xaar 50X Series combines PrecisionPlus architecture, excellent reliability and flexible configuration options to deliver sharp text, smooth graphics and consistent output across a wide range of applications.

Download datasheet

Applications

Versatile printing for graphics, coding and industrial applications

Designed for OEMs and print providers that need quality, uptime and integration flexibility

From banners, signage and point-of-sale materials to packaging, codes, logos and direct-to-shape printing, the Xaar 50X Series provides a flexible platform for wide-format graphics and industrial printing. Xaar 501 variants support graphics applications, while Xaar 502 variants extend the platform into coding and marking and other industrial uses.

Is the Xaar 50X Series right for you?

The Xaar 50X Series ideal if you need to:

Deliver smooth tints, graduations, sharp text and excellent edge definition

Achieve consistent drop formation and even density across a 70mm print swathe

Print graphics, text, barcodes and codes across flat or shaped products

Use flexible drop sizes from 8pL up to 75pL, depending on the selected variant

Access up to six grey levels for enhanced resolution, subtle graphics and productivity

Integrate multiple printheads easily using a uniform print swathe and compact design

Choose between oil, UV and solvent fluid compatibility across the Xaar 501 and Xaar 502 variants

Use selected variants with TF Technology, Ultra High Viscosity Technology and SureFlow self-cleaning

The challenge

Wide-format and industrial printing demand high quality without sacrificing uptime

Print providers and OEMs need to reproduce smooth graphics, sharp text and readable codes consistently, while maintaining reliable production in demanding environments. Variation in drop formation, velocity or placement can create visible density differences and make multi-head integration more difficult.

Applications can also require different fluids, drop sizes, throw distances and print orientations. A printhead platform must therefore provide the right balance of quality, robustness and configuration flexibility without adding unnecessary integration or servicing complexity.

How the Xaar 50X Series solves it

Precision, reliability and flexibility in one compact platform

PrecisionPlus architecture

Optimises actuator performance to deliver more uniform drop formation, improved velocity stability and precise drop placement across the print swathe.

Exceptional print quality

Provides smooth tints and graduations, strong edge definition and consistent reproduction of text, graphics and barcodes.

500 individually lasered nozzles

Supports accurate drop placement and consistent print quality across the 70.5mm print swathe.

Flexible drop capability

Offers fine drops from 8pL and larger drops up to 75pL, with up to six grey levels depending on the selected variant.

Industrial reliability

Engineered for demanding production environments, supporting consistent output and high production uptime.

Optional TF Technology

Selected recirculating variants keep fluid moving to help remove particles and air bubbles, prevent sedimentation and improve reliability with challenging inks.

High Laydown Technology

Provides higher fluid volumes for applications requiring stronger coverage, coatings or structured effects.

Variant flexibility

Xaar 501 and Xaar 502 configurations provide choices for wide-format graphics, coding and marking, fluid type, drop size, nozzle protection and recirculation.

Easy integration and servicing

A uniform swathe allows printheads to be mounted together more easily, supporting trouble-free integration, faster time-to-market and shorter servicing times.

Key benefits of inkjet printing with Xaar 50X...

Improve print quality

PrecisionPlus architecture, individually lasered nozzles and flexible greyscale capability support smooth tones, sharp detail and consistent density.

Protect production uptime

The robust industrial design and optional fluid recirculation features help maintain dependable operation in demanding environments.

Expand application range

A choice of Xaar 501 and Xaar 502 variants supports wide-format graphics, signage, packaging, coding and marking, and direct-to-shape printing.

Increase design flexibility

Flexible drop sizes and grey levels help balance fine detail, coverage and productivity for different print requirements.

Simplify integration

The compact 70mm swathe and uniform output make it easier to mount multiple printheads and achieve consistent results across the print width.

Print challenging fluids

Selected variants combine TF Technology and Ultra High Viscosity compatibility to support heavily pigmented and higher-viscosity fluids.

Reduce service disruption

Straightforward integration and short servicing times help OEMs and print providers return equipment to production quickly.

Choose proven architecture

The Xaar 50X Series builds on Xaar’s Hybrid Side Shooter architecture and industrial inkjet expertise.

501 Specification

TF Technology

No

Ultra High Viscosity Technology

No

High Laydown Technology

Yes

AcuChp Technology

Yes

SureFlow Self cleaning mode

No

In-line filter

Yes

Fluid Viscosity (cP)

XX

Max printhead temperature

XX

Active nozzles

500

Print swathe width (mm)

70.5

Number of rows

1

Nozzle pitch (µm)

141.1

Nozzle density (nozzles per inch)

180

Nozzle stagger (µm)

47

Nozzle guard

WFG

Maximum frequency up to (kHz)

8

Fluid Types

Oil-based

Drop size* (pL)

8 to 40

Drop velocity* (m/s)

5

Number of grey levels*

6
* Dependent on ink used and system integration


Hight (mm)

104

 Depth (mm)

17

 Width (mm)

104

 Printhead dry weight (g)

208



TF Technology

Yes

Ultra High Viscosity Technology

Yes

AcuChp

Yes

In-line filter

Yes

Active nozzles

500

Print swathe width (mm)

70.5

Number of rows

1

Nozzle pitch (µm)

141.1

Nozzle density (nozzles per inch)

180

Nozzle stagger (µm)

47

Nozzle guard

WFG

Maximum frequency up to (kHz)

8

Ink Type

Oil-based

Drop size* (pL)

8 to 40

Drop velocity* (m/s)

5

Number of grey levels*

6
* Dependent on ink used and system integration


Hight (mm)

100

 Depth (mm)

17

 Width (mm)

104

 Printhead dry weight (g)

205



TF Technology

No

Ultra High Viscosity Technology

Yes

AcuChp

Yes

In-line filter

Yes

Active nozzles

500

Print swathe width (mm)

70.5

Number of rows

1

Nozzle pitch (µm)

141.1

Nozzle density (nozzles per inch)

180

Nozzle stagger (µm)

47

Nozzle guard

WFG

Maximum frequency up to (kHz)

8

Ink Type

UV curable

Drop size* (pL)

8 to 40

Drop velocity* (m/s)

5

Number of grey levels*

6
* Dependent on ink used and system integration


Hight (mm)

113

 Depth (mm)

17

 Width (mm)

104

 Printhead dry weight (g)

208



TF Technology

Yes

Ultra High Viscosity Technology

Yes

AcuChp

Yes

In-line filter

No

Active nozzles

500

Print swathe width (mm)

70.5

Number of rows

1

Nozzle pitch (µm)

141.1

Nozzle density (nozzles per inch)

180

Nozzle stagger (µm)

47

Nozzle guard

WFG

Maximum frequency up to (kHz)

8

Ink Type

UV curable

Drop size* (pL)

8 to 40

Drop velocity* (m/s)

5

Number of grey levels*

6
* Dependent on ink used and system integration


Hight (mm)

113

 Depth (mm)

17

 Width (mm)

104

 Printhead dry weight (g)

208



502 Specification

TF Technology

No

Ultra High Viscosity Technology

No

AcuChp

Yes

In-line filter

Yes

Active nozzles

500

Print swathe width (mm)

70.5

Number of rows

1

Nozzle pitch (µm)

141.1

Nozzle density (nozzles per inch)

180

Nozzle stagger (µm)

47

Nozzle guard

WFG

Maximum frequency up to (kHz)

8

Ink Type

Solvent based

Drop size* (pL)

8 to 40

Drop velocity* (m/s)

5

Number of grey levels*

6

* Dependent on ink used and system integration









Hight (mm)

104

Depth (mm)

17

Width (mm)

104

Printhead dry weight (g)

208



TF Technology

Yes

Ultra High Viscosity Technology

Yes

AcuChp

Yes

In-line filter

Yes

Active nozzles

500

Print swathe width (mm)

70.5

Number of rows

1

Nozzle pitch (µm)

141.1

Nozzle density (nozzles per inch)

180

Nozzle stagger (µm)

47

Nozzle guard

WFG

Maximum frequency up to (kHz)

8

Ink Type

Solvent based

Drop size* (pL)

8 to 40

Drop velocity* (m/s)

5

Number of grey levels*

6

* Dependent on ink used and system integration









Hight (mm)

100

Depth (mm)

17

Width (mm)

104

Printhead dry weight (g)

205



TF Technology

No

Ultra High Viscosity Technology

Yes

AcuChp

Yes

In-line filter

Yes

Active nozzles

500

Print swathe width (mm)

70.5

Number of rows

1

Nozzle pitch (µm)

141.1

Nozzle density (nozzles per inch)

180

Nozzle stagger (µm)

47

Nozzle guard

C&M

Maximum frequency up to (kHz)

8

Ink Type

Oil-based

Drop size* (pL)

8 to 40

Drop velocity* (m/s)

5

Number of grey levels*

6

* Dependent on ink used and system integration









Hight (mm)

113

Depth (mm)

17

Width (mm)

104

Printhead dry weight (g)

208



TF Technology

Yes

Ultra High Viscosity Technology

Yes

AcuChp

Yes

In-line filter

No

Active nozzles

500

Print swathe width (mm)

70.5

Number of rows

1

Nozzle pitch (µm)

141.1

Nozzle density (nozzles per inch)

180

Nozzle stagger (µm)

47

Nozzle guard

C&M

Maximum frequency up to (kHz)

8

Ink Type

Oil-based

Drop size* (pL)

8 to 40

Drop velocity* (m/s)

5

Number of grey levels*

6

* Dependent on ink used and system integration









Hight (mm)

113

Depth (mm)

17

Width (mm)

104

Printhead dry weight (g)

208



Compare printheads

9843 Xaar_TFT_logo_white.png

Xaar’s nozzle level piezo printhead ink recirculation technology which transformed industrial inkjet printing

Explore more

9843 Xaar_HighLdown_logo_white.png

Give you the ability to deposit large quantities of fluid
in each pass

Explore more

10167 Xaar_UHV.white.png

Allows you to reliably print fluids around
100 centipoises (cP) at jetting temperature,
(approx. 1000cP at ambient temperature) which is well beyond average jetting capabilities of 10-12cP

Explore more

Frequently asked questions...

The Xaar 50X Series is used in graphics and signage applications across substrates such as vinyl, paper, foam board, laminate and textiles. It is relevant where manufacturers or printer developers need reliable digital print capability for wide-format, display, décor or visual communication applications.

The Xaar 50X Series can support printing where consistent output, substrate flexibility and reliable operation are important. Potential applications include display graphics, printed signs, promotional materials and visual communication products produced on media such as vinyl, paper, foam board and laminates.

The Xaar 50X Series can be used for printing on vinyl and other flexible media where the ink, surface treatment and production process are compatible. This can support graphics, signage and décor applications where flexible substrates are commonly used.

The Xaar 50X Series may be suitable for applications involving paper, foam board and laminate, subject to ink compatibility, substrate handling and production requirements. These substrates are commonly used in graphics, signage, display and decorative print environments.

The Xaar 50X Series can be used for textile printing applications where the ink, fabric, pre-treatment and production workflow are compatible. Textile suitability depends on the print process, colour and quality requirements, drying or curing method and how the printhead is integrated into the system.

The Xaar 50X Series is used in graphics and wide-format print systems because it can support a range of visual communication and substrate-led applications, including vinyl, paper, foam board, laminates, textiles and signage. OEMs and manufacturers should assess substrate range, ink compatibility, print width, quality, speed and maintenance requirements when selecting the printhead.
